The use of volcanic ash as a cement raw material dates back to ancient Roman times. As early as the 1st century BC, the Romans began utilizing volcanic ash to improve building materials. They discovered that volcanic ash possesses excellent binding properties and can react with lime to form strong concrete. This mixture was widely used in Roman architecture, particularly in the construction of structures like the Pantheon, Roman aqueducts, and other large-scale buildings, showcasing exceptional durability and strength.

With the advancement of the Industrial Revolution in the early 20th century, scientists recognized the outstanding properties of volcanic ash and began to reintroduce it in modern cement production. The primary advantages of volcanic ash include its rich content of reactive silicates and aluminates, which can react with the components in cement to enhance the strength and durability of concrete.

The use of volcanic ash in the cement industry has also promoted the utilization of other waste resources, such as fly ash, thereby reducing the demand for natural resources.

Both fly ash and volcanic ash contain abundant reactive silicates and aluminates, which can react with calcium silicates in cement to form additional binding materials, enhancing the strength and durability of the cement.

When finely ground, fly ash typically has a higher fineness and specific surface area, providing excellent filling properties in cement, which further improves the density and impermeability of concrete.

Fly ash is an industrial waste collected from coal-fired power plants. Once processed, its main components (such as silicon dioxide, alumina, and iron oxides) offer hydration reactions similar to volcanic ash.

The acquisition and processing costs of fly ash are generally lower than those of volcanic ash. As an industrial byproduct, fly ash is relatively inexpensive, which helps reduce cement production costs and waste disposal expenses. Moreover, using fly ash instead of volcanic ash helps lower carbon dioxide emissions in cement production, aligning with environmental requirements.

Fly ash is widely available in many regions, especially where volcanic ash resources are limited or difficult to obtain. This makes fly ash an ideal substitute for volcanic ash in cement production, addressing economic, performance, and environmental considerations.

Fly ash is an industrial byproduct generated in coal-fired power plants during the combustion of coal. In these power plants, coal is fed into boilers where it is burned. During the combustion process, coal releases heat energy and generates gases and solid residues. At high temperatures, unburned coal dust and particles are carried into the flue gas.

These fine particles travel with the flue gas. To control environmental pollution and recover coal ash, power plants use dust collection equipment. The collected fly ash is then cooled and stored in ash storage silos.

To enhance its industrial application value, fly ash typically undergoes further processing, such as drying and fine grinding, to improve its properties.

Fly ash is widely used as a mineral admixture in cement production, primarily by being mixed with cement clinker to enhance the properties of cement. By combining fly ash with cement clinker, the workability of the cement can be significantly improved.

The fine granularity and excellent flowability of fly ash make concrete easier to handle and pour during construction, reducing the difficulty of the construction process. Additionally, fly ash can react with calcium silicates in cement to form additional binding materials, thereby increasing the strength and durability of the concrete.

Fly ash can also be used to produce various types of high-performance cement. In Portland cement, the inclusion of fly ash can optimize the cement's performance, enhancing its durability and impermeability. In slag cement, the combination of fly ash and slag not only increases the cement's strength but also improves its crack resistance and high-temperature performance.

Clinker-free cement does not contain traditional cement clinker and primarily relies on mineral admixtures such as fly ash and slag for its binding properties. Fly ash serves as a main component and is mixed with other materials like gypsum and limestone to form clinker-free cement.

Incorporating fly ash into clinker-free cement can enhance the compressive strength of concrete. For instance, cement with 30% fly ash content typically achieves a 28-day compressive strength of 35-45 MPa, which is comparable to traditional cement.

Construction Materials:
Lightweight Concrete: Fly ash is used to produce lightweight concrete, enhancing its thermal insulation and soundproofing properties, making it suitable for building walls, partitions, and floors.
Fly Ash Bricks and Blocks: These bricks offer high compressive strength, reduce production costs, and minimize the demand for natural soil resources. They are widely used in building construction.

Road Construction:
Soil and Aggregate Stabilizer: Fly ash is utilized to improve the strength and stability of the road base, increasing the load-bearing capacity of roads.
Cold Recycling: In road rehabilitation, fly ash is used in cold recycling mixtures to enhance the performance of old pavements, lowering construction and maintenance costs.

Landfill and Environmental Applications:
Landfill Filler: Fly ash helps in stabilizing and isolating waste in landfills, reducing environmental pollution.

Soil Amendment:
Used as a soil improver, fly ash enhances soil water retention and aeration, benefiting plant growth and land reclamation efforts.

Water Treatment:
Adsorbent: Fly ash serves as an adsorbent to remove heavy metal ions and organic pollutants from water, improving water quality to meet environmental standards.

Agriculture:
Soil Conditioner and Fertilizer: Fly ash can improve soil structure and fertility, promoting crop growth and increasing agricultural productivity.

Fly ash's versatility across different industries showcases its potential to not only enhance material performance and reduce costs but also contribute to environmental sustainability.
